High Quality Sanitary Pressure Transmitter YS2

High Quality Sanitary Pressure Transmitter YS2

Share To :
  • Product Details

High Quality Sanitary Pressure Transmitter YS2


Application & Features:

  • Food and sanitatin
  • Paper-making
  • Measurement of sewage level
  • Measurement of beverage jar
  • Measurement of pipe level
  • Machining of medicine, pharmacy, biological goods
  • Sensor is closed off from measuring media by stainless steel ripple and is very sanitary
  • Protection of reverse poarity and current limit
  • Radial-resistent, multiplicate output signal, zero and full scale adjustable
  • Compact design,pretty,cheap but high quality
  • High precision, stability, reliability
  • Transmitter is mounted with SUS316 tri-clamp, filled with sanitary oil


Specification:

Media

Liquid, air and steam which is compatible to SUS316L stainless steel

Range

-100kPa~40MPa

Overload

150% of full scale

Accuracy

±0.5%、±1%

Long stability

±0.25%FS/year

Temperature error

±0.025%FS/℃(in relation to 25℃)

Working temperature

-10~+70℃(standard compensation)-20~+85℃(special compensation)

Storage temperature

-40~+125℃

Relative humidity

0~95%RH

Working Voltage

12-36VDC(standard 24VDC)±5%, ripple: less than 1%

Output signal

4~20mADC

Load resistance

R=(U - 13)/0.02 – RD: Note: U is voltage, RD is cable inner resistance

Zero drift

±20% of output range

Range adjustable

±20% of output range

Impact  of power supply

Less than 0.01%/v of output range

Impact of load

Ignore

Impact of temperature

±2.5%FS/(class0.25)±5.0%FS/(class0.50)、(In realation to 25℃,compensation:-20~85℃, impact of zero and full scale  )



Pictures:
