Case material:
Stainless steelWetted Parts:
BrassCertification:
ISO9001Quality:
100% Inspection
UL spiral tube oxygen pressure gauges meter manometer
Brief:
For medical oxygen pressure gauges, we have UL certification available for1.25" oxygen pressure gaugesand 1.5" 3000psi pressure scale.
Application & Features:
• 1.25" , 1.5" sizes
• 1/8" NPT back socket
• Safety over-pressure port on the lens
• "Use No Oil" for use in oxygen service
• UL Listed for 1.25” & 1.5" 3000psi ,UL number:SA32781
• Commonly used on portable pneumatic equipment such as compressors, hand-held sprayers, pressurized recreational guns, oxygen tanks and regulators, pumps and fire extinguishers
Specifications:
|
Dial |
1.25” or 1.5” white aluminum with black markings |
|
Case |
304 SS |
|
Lens |
Plexiglass |
|
Spiral Tube |
phosphor bronze or Stainless steel316L |
|
Connection |
1/8” NPT standard, back |
|
pointer |
3000 psi and below: Brass |
|
Over-Pressure Limit |
10% of full scale value |
|
Working Pressure |
10% of full scale value |
|
Ambient |
-40°F to 150°F (-40°C to 65°C) |
|
Accuracy |
±3-2-3% ANSI/ASME Grade B |
|
Enclosure Rating |
IP65 |
Product Pictures:
Dimension:
Leave A Message2.5" Medical system black steel bottom mount single diaphragm medical pressure gauge, which is used inVacuum pumps, air compressors, air filters, gas burners, vacuum ovens, suction regulators and respirators
2.5" Black steel central panel mounted medical manometers, which is used medical company.
2.5" Medical system black steel back entry low pressure indicator with U-clamp, which is used inVacuum pumps, air compressors, air filters, gas burners, vacuum ovens, suction regulators and respirators
2.5" Medical system black steel lower mount single diaphragm medical manometer, which is used inVacuum pumps, air compressors, air filters, gas burners, vacuum ovens, suction regulators and respirators
1.25" Spiral tube medical oxygen pressure gauges, which is used for medical systems.
1.25" Spiral tube medical oxygen pressure gauges, which is used for medical systems.
2.5" Medical system black steel central mount single diaphragm medical pressure gauges, which is used in medical systems.
Medical system pressure gauges with high and low pressure, which is used medical company.
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
